3. Display (DISP) Button:
Touch to adjust the screen brightness.
Touch and hold to turn the screen o.
When the TFT is closed, press once and repeat to cycle through clock time,
metadata, RDS information, etc. The type of information displayed depends
upon the selected source
4.
3�5 mm AV IN Jack:
This connector accepts a 3.5 mm jack through which signals from various
audio/video devices can be applied to the unit.
5.
Open Button:
Press to open/close the TFT/LCD screen.
6.
Reset Button:
Press this button to reset the system settings (except password and parental
lock settings) and to correct a system halt or other illegal operation. Use the
tip of a pen to press the Reset button.
7.
Micro SD Card slot:
Playback of music/video files.
8.
USB slot:
Used to connect an iPod®, MP3 player or flash d
evice connection adapter
for playback of music/video file .
9.
Interface Cover:
Covers the MicroSD card slot, USB slot and Reset button.
10. Remote Sensor:
Used to receive command signals from the remote control.
11.
Previous ( ) / Next ( ) Buttons:
Press the Previous ( ) button to play the previous track on a disc.
Press the Next ( ) button to play the next track on a disc.
12. Rotary Volume ( ) Knob / Mute Button
Rotate the knob to adjust the volume from 0 to 50.
Press the knob momentarily to mute the audio. Press the knob again to
restore the audio.
13. SRC / Power On/Off ( ) Button
Press to turn the unit ON.
When on, press to switch the playing source.
Press and hold to turn the unit o.
14. Disc Slot:
Accepts DVD/CD/MP3 discs. If the unit is turned on, playback begins when a
disc is inserted.
To Next Page
