Jensen XA4150 - Speaker Wiring; 4 Speakers; 2 Subwoofers;Bridged Mono

7
®
XA4150
Speaker Wiring
The XA4150 amplifier has inputs and outputs for four channels
2 Subwoofers/Bridged Mono4 Speakers
A-CH B-CH C-CH D-CH
+ –
–
+
+ –
–
+
RCA Cables
2/4Ω
2/4Ω 2/4Ω
2/4Ω
OFF ON
LPF
FULL
HPF
BASS-BOOST
OFF ON
BASS-BOOST
X-OVER
LPF
FULL
HPF
X-OVER
CH 1/2
CH 3/4
4CH
3CH
2CH
MODE
A-CH B-CH C-CH D-CH
+ –
–
+ + –
–
+
RCA Cables
4Ω
4Ω
minimum
4Ω
minimum
4Ω
OFF ON
LPF
FULL
HPF
BASS-BOOST
OFF ON
BASS-BOOST
X-OVER
LPF
FULL
HPF
X-OVER
CH 1/2
CH 3/4
4CH
3CH
2CH
MODE
