Jerr-Dan MPL40 User Manual

Section II: Operation
Page 27
5-376-000086
REV. 4 - 07/10
3. Place the hook of the ratchet into
one of the holes on the front side
of the grid. Again, try to use the
hole that is closest to the tire.
NOTE:
The hole on the outside of the
grid can be used to hook the
ratchet in if you need to clear
body mouldings or wide tires.
4. Take up the slack in the strap by
ratcheting the takeup spool arm.
Continue until the tires show
some compression. Notice that
the strap in the ratchet is
pulling down and forward on
the loop over the tire.
5. Raise the wheel grid to the tow-
ing position. RE-TIGHTEN THE
RATCHET PERIODICALLY AS
THE TIRE SETTLES IN GRID
FROM TOWING.
NOTE:
Never tow a vehicle without
tire tie-down straps and
safety chains installed.
