Jerr-Dan MPL40 - Equipment Ratings and Specifications

Section I: Safety
Page 3
5-376-000086
REV. 4 - 07/10
DO NOT EXCEED THE FOLLOWING RATINGS:
MPL40 Underlift Rating ....................................... 4,000 lbs “L” Arm
2
Tow Rating ..................................................................... 7,500 lbs.
2
Boom Rating: (Extended)...............................................6,000 lbs.
(Retracted) ............................................ 16,000 lbs.
Winch Rating: (Ramsey Worm Gear Winches)
1
.....................
8,000 lbs.
(Warn Planetary Gear Winch)
1
.........................
9,000 lbs.
Wire Rope:
Working Limit ................................................4,100 lbs.
Construction ............................ 6 x 25 EIPS RRL IWRC
Diameter ........................................................... 3/8 inch
Standard Length ..............................................100 Feet
1
SAE J706: Surface Vehicle Recommended Practices - Rating of Winches
2
SAE J2512: Surface Vehicle Recommended Practices - Towing
Equipment Ratings and Practices
MAXIMUM LIFTING CAPACITY - THE MAXIMUM LOAD THAT CAN BE LIFTED.
GROSS COMBINED WEIGHT RATING (GCWR) - THE VALUE SPECIFIED BY THE VEHICLE
MANUFACTURER AS GCW.
GROSS COMBINED WEIGHT (GCW) - ACTUAL WEIGHT OF THE ENTIRE VEHICLE AT THE
GROUND WITH TRAILER OR TRAILERS, INCLUDING VEHICLE EQUIPMENT, DRIVER, PAS-
SENGER, FUEL AND PAYLOAD (EVERYTHING THAT MOVES WITH THE VEHICLE).
