Section II: Operation
Page 29
5-376-000086
REV. 4 - 07/10
TOWBALL HITCH ATTACHMENT
The MPL40 is supplied with a Towball Hitch attachment that will allow you
to recover and tow trailers requiring a tow ball hookup.
DO NO EXCEED THE FOLLOWING RATINGS:
1-7/8 in. Ball:................................5,000 lbs. (GTW)*
2 in. Ball: .....................................5,000 lbs. (GTW)*
2-5/16 in. Ball:..............................7,500 lbs. (GTW)*
50 MM Ball: .................................5,000 lbs. (GTW)*
* Gross Tongue Weight
1. Remove the towball hitch
attachment from the toolbox.
2. Install the towball hitch to the
bottom on the underlift boom using
the hitch pins.
3. Secure the hitch pins with the
linch pins.
To Next Page
