Section II: Operation
Page 28
5-376-000086
REV. 4 - 07/10
WHEEL GRID SPACERS
The MPL40 with the self loading grid is supplied with a set wheel grid spacers.
They can be used to pick up a vehicle with small diameter tires or even a
vehicle without wheels and tires.
The following steps should be
followed to properly install the wheel
grid spacers:
1. Slide the back side of the wheel
spacer over the wheel grid arm.
2. Close the grid arms around the
tires to secure the towed vehicle.
Make sure that the arm is fully
closed and in its over center
locked position.
3. Visually inspect the tire to grid
contact before proceeding.
