Section II: Operation
Page 40
5-376-000086
REV. 4 - 07/10
10. Re-engage the winch drive by
pushing down on the spring steel
latch plate and turning the handle
180°. Confirm winch engagement
by jogging the winch control. Now
slowly take up the slack in the
wire rope.
11. With the wire rope tight, slowly
wind it in, observing both the work
and the drum. Be sure the wire
rope strands do not cross wrap
or criss-cross on the drum.
Observe the path the work must
travel for snags or obstructions
which could stall the movement
and overload the wire rope.
