Jerr-Dan MPL40 User Manual

Section II: Operation
Page 59
5-376-000086
REV. 4 - 07/10
4. Hook the loading ramp onto the
wheel grid and engage the rear
hooks on the back side of the
grid.
5. Completely retract the wheel grid
for loading.
6. Attach the lower trough and
vertical stop into the mounting
bracket at the front of the boom
with the pin and retaining pin.

Jerr-Dan MPL40 Specifications

General

Brand	Jerr-Dan
Model	MPL40
Category	Utility Vehicle
Language	English
