Jesco MEMDOS E - Page 35

Valves DN 10, MEMDOS E/DX 160...380
Double-ball valves Spring-loaded valves
Discharge valve Suction valve Discharge valve Suction valve
h
g
c
b
f
i
d
a
e
h
b
d
e
f
g
c
a
i
h
g
d
c
a
b
f
e
d
h
g
c
d
d
e
b
a
f
e
f
b
f
e
b
a * Flat gasket
b * Flat gasket
c Valve body
d Ball guide
e * Valve ball
f * Valve seat
g * Flat gasket
h * Flat gasket
i * Pressure spring
* included in the spare parts set.
Maintenance | Operation & Maintenance Instructions | 35
