Jet DC-1200-M - 5 Assembly and Start up; Contents of Delivery; Installation; Noise Emission

Mains 3~400V,PE,50Hz
Outputpower 1,5kW(2HP)S1
Referencecurrent 2.8A
Extensioncord(H07RN‐F) 4x1,5mm²
Installationfuseprotection 16A
Protectionclass I
Overall(LxWxH) 1000x750x2000mm
Netweight 40kg

4.2Noiseemission
Measured,in1mdistance,1.6mabovethefloor,withflexible
hoseconnected.(inspectiontolerance4dB).
Acousticpressurelevel
(ENISO11202): LpA80dB(A).
Thespecifiedvaluesareemissionlevelsandarenot
necessarilytobeseenassafeoperatinglevels.
Asworkplaceconditionsvary,thisinformationisintendedto
allowtheusertomakeabetterestimationofthehazardsand
risksinvolvedonly.

4.3Contentofdelivery
Filterbag
Collectionbag
Mobilecasters(4x)
Dustinlet2x100mm
Hoseclamps100mm(2x)
Hosegroundwire
Operatingmanual
Sparepartslist

4.4Unitdescription

Fig1


Fig2
A….Hose
B….CollectorBody&Fan/MotorAssembly
C….Housing
D….Base
E….FilterBagHanger
F….SupportRods(3x)
G….Inlet
H….FilterBag
I…..Gasket
J….MobileCasters(4x)
K….Hex.Bolts(M8x16,18pc;M8x25,4pc;M6x20,6pc)
 Hex.Nuts(M8,4pc;M6,6pc)
 HeadScrews(M6x10,16pc)
 Washer(M8,26pc;M6,28pc)
 Hex.Wrench(5mm,1pc)
L….MotorBase
M…Handle
N….RetainerStrap(2x)
O….Hose
P…..HoseClamp(2x)
Q….CollectorBag
R…..Switch
S……Motor
T……CEEPlug(400V)orWirePlug(230V)
W….Outletconnector


5.Assemblyandstartup
5.1Installation
Themachineisdesignedtooperateindry,enclosedrooms
andmustbeplacedstableonfirmandlevelledground.
Theroomtemperaturemustbebetween+5°Cand+40°C.
