Jet DC-1200-M - Changing Collector Bag; Cleaning Filter; 6 Machine Operation; Mains Connection


Fig12
Attention:
Hosesandductwork,mustbegroundconnected(PE),to
avoidelectro‐staticcharging,whichcouldcauseignition‐
sparks.
(JETDustCollectionGroundingKit,ArticleNumber:JW1053).

5.4Mainsconnection
Mainsconnectionandanyextensioncordsusedmustcomply
withapplicableregulations.
Themainsvoltagemustcomplywiththeinformationonthe
machinelicenceplate.
Themainsconnectionmusthavea16Asurge‐prooffuse.
OnlyusepowercordsmarkedH07RN‐F
Connectionsandrepairstotheelectricalequipmentmayonly
becarriedoutbyqualifiedelectricians.

6.Machineoperation
Youcanstartandstopthemachinewiththemagneticswitch
(R,Fig13).
Attention:
(400Vversion)ifthedirectionofrotationisnotcorrect,the
phaseconverterinsidetheCEEEuroplug(T)mustbepushed
inandturned180°.
(Seerotationarrowonmachineforcorrectrotation)

Fig13




7.Maintenanceandinspection
Generalnotes:
Maintenance,cleaningandrepairworkmayonlybecarried
outafterthemachineisprotectedagainstaccidentalstarting
bypullingthemainsplug.
Inspecttheproperfunctionofthedustcollectionsystem
daily.
Cleantheunitregularly.
Defectivesafetydevicesmustbereplacedimmediately.
Repairandmaintenanceworkontheelectricalsystemmay
onlybecarriedoutbyaqualifiedelectrician.
7.1CleaningFilter
Thefiltermustbecleanedwhentheairflowreduces,and
beforechangingthecollectingbag.
Shakethefilterbagwheneveritiscloggedandbeforeeach
collectorbagchange.
Duringthecleaningofthefilterbagit’snecessarytousea
mask(maskwithfiltration).
7.2Changingcollectorbag
Alwaysdisconnectthedustcollectorfromthepowersource
(unplug)beforeservicingorchangingfilter.
Duringthechangingorcleaningofthecollectorbagit’s
necessarytouseamask(maskwithfiltration).

8.Troubleshooting
 Unitdoesn’tstart
*Noelectricity‐
checkmainsandfuse.
*Defectiveswitch,motororcord‐
consultanelectrician.
 Airflowtooweak
*Cloggedfilter‐
cleanfilter.
*Collectionbagisfull‐
changethebag.
*Wrongmotorrotatingdirection(400Vversion)‐
changedirection(seechapter6).

9.Environmentalprotection
Protecttheenvironment.
Yourappliancecontainsvaluablematerialswhichcanbe
recoveredorrecycled.Pleaseleaveitataspecialized
institution.

Thissymbolindicatesseparatecollectionforelectricaland
electronicequipmentrequiredundertheWEEEDirective
(Directive2012/19/EC)andiseffectiveonlywithinthe
EuropeanUnion.


