Jet GH-20 ZH Series User Manual

8
5.0 Dimensions and mounting hole centers
Figure 1
Lathe Size
80 inch
(GH-2680ZH)
120 inch
(GH-26120ZH)
A 2560mm(100.8 in.) 3565mm(140.4 in.)
B 3500mm(137.60 in. ) 4500mm (177.2 in.)
C 1721.5mm (67.8 in)
Table 1
