Operation Manual
Total 21
page 12
4.3 Machine operation
Put the switch (QSA1) at the position which is required (“1” main motor 1440 r/min.”2”main
Motor 2880 r/min, “R” the reversion of main motor, “0” machine is stopped). Press the button
SB3, it is working normally. When put the switch (QSA1) at “R”
working.
4.4 Emergency stop operation:
If emergency stop is necessary during operation, press emergency push button SQ1 that makes
the loss of electric power of the contactor KM1, so the machine is completely stopped. After
eliminating the breakdown , release the lock of the push button then restart the machine.
4.5 Maintenance of the electric equipment:
Turn off the electric power before maintenance of the electric equipment starts. The electric
equipment must keep on clean condition. Therefore, regularly cleaning is necessary.
However .liquid such as kerosene, gasoline and detergent etc. is not be allowed for the
cleaning. Wave of power supply shall not be over ±10% required by the electric motor.
Maintenance of electric equipment is absolutely important in order to keep machine works
well.
