Jet GHD-25 User Manual

Operation Manual
Total 21
page 13
4.7 Electric components list:
Table (3)
Code of
elements
Name Specification Q’ty Remark
QS1 Instruction switch
JCH13-20
1
QF1 Breaker
DZ108-1.6/2.5A
1
KM1,KM2
Connector
LC1E1201B5N(AC24V)50Hz
2
LAEN20N
2
SB1 Emergency stop button
LA42(B)J-11/R
1
SB2 Push button
LA42(B)PJ-11/R
1
SB3,SB4 Push button
LA42(B)PJ-22/G
2
HL1 Signal lamp
AD17-16 AC24V
1
T1 Transformer
JBK6-63TH 400/24
1
EL1 Lamp
25W AC24V
1
SX1 Selection switch LA42XL2-30/B 1
SQ1 Micro switch LXP1-020-0A 1
SQ2 Door switch JWM6-11A 1
