Op
eration Manual
Total 21
page 3
2. Main technical data:
2.1 Main technical data
No. Name of the items
Unit Data
1 Max. drilling diameter (steel) mm 25
2 Max. tapping diameter (steel) mm M18
3
Distance between spindle center line to the center line
of column
mm 240
4
Max. distance between spindle end to the worktable
surface of the base
mm 650
5 Max. stroke of the spindle mm 110
6 Spindle taper MT3
7 Number of speed steps of the spindle Step 6
8 Working area of the worktable of the base (L x W) mm 335×340
9 Numbers and width of the T slots of base mm 2-T14
10 Diameter of column
mm
φ110
11 Power and speed of the main motor kW, rpm 0.75, 1400
12 Machine dimension (L x W x H)
mm
700×460×1425
13 Net weight of the machine (Net weight)
kg
220
