Unpacking
Contents of Shipping Container
1 Bending Die (A) – see also Table 1
1 Hardware Bag (B)
1 Hydraulic Pump Unit (C)
1 Tripod Seat (D)
1 Swaging Block (E)
1 Support Assembly (F)
1 Hinge Pin (G)
1 Upper Wing Plate (H)
1 Lower Wing Plate (J)
1 Handle (K)
3 Tripod Leg (L)
3 Tripod Pole Base (M)
Bending
Die Size
Model
JHPB-20 (2-in) JHPB-30 (3-in)
01/2" x x
03/4" x x
01" x x
01-1/4" x x
01-1/2" x x
02" x x
02-1/2" x
03" x
Table 1
Table 1 lists the bending die sizes that are included
with each hydraulic pipe bender model.
Contents of Hardware Bag
4 Double-Ended Threaded Stud (M)
4 M12 Lock Washer (N)
4 M12 Hex Nut (O)
1 Vented Oil Plug (P)
1 O-Ring (Q)
1 Cotter Pin (R)
Figure 1: Shipping Contents
Figure 2: Contents of Hardware Bag
