6
4.0 Features
Figure 4-1
5.0 Specifications
Table 1
Model number
JJ-6HHBT
Stock number 718600
Motor Brushed DC, 115V, 60Hz, 15A
On/off switch toggle switch with safety key
Recommended circuit size
1
15A
Sound emission
2
92 dB
Cutterhead speed 10,000 RPM
Cutterhead diameter 2 in. (50.8 mm)
Number of knives 14 inserts in 2 spiral rows
Cutter knife size (LxWxT) 0.59 x 0.59 x 0.10 in., R6/37° (HM15x15x2,5 mm R150/ 37°)
Dust port diameter 2-3/8 in. (fits 2-1/2 in. dust hose)
Jointer table 28-5/8 x 6-1/4 in. (727 x 159 mm)
Maximum stock removal 1/8 in. (3.175 mm)
Maximum cutting width 6 in. (152.4 mm)
Fence 22-3/4 x 4-3/8 in. (578 x 111 mm)
Fence tilt 45° L, 90°, 45° R
Fence positive stop 45° L, 90°, 45°R
Overall dimensions (LxWxH) 30 x 20 x 13 in. (762 x 508 x 330 mm)
Net weight 71 lbs. (32 kg)
Shipping weight 76 lbs. (34 kg)
1
subject to local/national electrical codes
2
The specified values are emission levels and are not necessarily to be seen as safe operating levels. As workplace
conditions vary, this information is intended to allow the user to make a better estimation of the hazards and risks
involved only.
L = length, W = width, H = height, T = thickness
The specifications in this manual were current at time of publication, but because of our policy of
continuous improvement, Powermatic reserves the right to change specifications at any time and without
prior notice, without incurring obligations.
