24
Closed Stand Assembly
Index Part
No. No. Description Size Qty.
1..........JSG96-301....................... Base.............................................................. ...................................1
2..........JSG96-302....................... Lock Nut........................................................ 3/8..............................4
3..........PJE-S05........................... Wheel............................................................ ...................................4
4..........JSG96-304....................... Hex Head Screw* .......................................... 3/8x2-1/2....................8
5..........JSG96-305....................... Shaft ............................................................. ...................................1
6..........PJN-S04 .......................... Eccentric Cam............................................... ...................................2
7..........JSG96-307....................... Set Screw...................................................... M6x10 ........................2
8..........JSG96-308....................... Spring............................................................ ...................................2
9..........JSG96-309....................... Roll Pin ......................................................... 4x16...........................2
10........PJN-S02 .......................... Foot Brake..................................................... ...................................1
11........JSG96-311....................... Lock Nut........................................................ M10x1.5 .....................1
12........TS-0720091 ..................... Lock Washer*................................................ 3/8..............................4
13........TS-0680041 ..................... Flat Washer* ................................................. 3/8..............................4
14........JSG96-314....................... Tool Shelf...................................................... ...................................1
15........TS-0060031 ..................... Hex Head Screw* .......................................... 3/8x3/4 .......................1
16........JSG96-316....................... Washer* ........................................................ 3/8x1-1/8....................1
17........JSG96-317....................... JET Plaque.................................................... ...................................1
18........JSG96-318....................... Door.............................................................. ...................................1
19........JSG96-319....................... Latch............................................................. ...................................1
20........JSG96-320....................... Screw............................................................ M3..............................2
21........JSG96-321....................... Door Pivot..................................................... ...................................1
22........JSG96-127....................... Screw............................................................ 1/4x3/8 .......................2
23........TS-0561011 ..................... Hex Nut......................................................... 1/4..............................2
............JSG96-HKB ..................... Hardware Kit for Closed Stand (includes items marked with *)
WMH Tool Group
2420 Vantage Drive
Elgin, Illinois 60123
Phone: 800-274-6848
www.wmhtoolgroup.com
