5.0 Specifications

Model Number ................................................................................... JVM-836-1..................................... JVM-836-3

Stock Number ......................................................................................... 690036........................................... 690038

Motor and Electricals:

Motor type .................................................................................. TEFC induction............................... TEFC induction

Horsepower ................................................................................................ 1-1/2.............................................. 1-1/2

Phase ............................................................................................................... 1.................................................... 3

Voltage ....................................................................... 115/230V (prewired 115V)....................................... 230V only

Cycle ..........................................................................................................60Hz.............................................. 60Hz

Listed FLA (full load amps) ........................................................................... 18/9............................................ 4.7/5.7

Power Transfer ............................................................................................. belt................................................. belt

Motor Speed ...................................................................................... 1720 RPM............................... 1720/840 RPM

Sound Emission (tested at 3 ft. from machine):

Without load.......................................................................................... 75 dB............................................. 75 dB

With load ......................................................................................... 80-85 dB........................................ 80-85 dB

Head and Spindle:

Spindle Taper ............................................................................................... R-8................................................. R-8

Quill Diameter ............................................................................................ 3-3/8”............................................. 3-3/8”

Number of Spindle Speeds................................................................................ 5.................................................. 10

Range of Spindle Speeds ..................................................................... 240-1550........................................ 120-1550

Spindle Travel .................................................................................................5”................................................... 5”

Head Movement ...............................................................................90° L and R.................................... 90° L and R

Maximum Distance Spindle to Table ......................................................... 13-3/4”........................................... 13-3/4”

Maximum Distance Spindle to Column ..................................................... 15-3/4”........................................... 15-3/4”

Minimum Distance Spindle to Column ........................................................ 5-1/4”............................................. 5-1/4”

Collet Capacity ................................................................................... 1/8” – 7/8”.......................................1/8” – 7/8”

Ram Travel .............................................................................................. 10-1/2”........................................... 10-1/2”

Ram Rotation ...................................................................................90° L and R.................................... 90° L and R

Table:

Table Size ................................................................................... 7-7/8 x 35-3/4”................................ 7-7/8 x 35-3/4”

Longitudinal Table Travel ......................................................................... 22-1/4”........................................... 22-1/4”

Table Cross Travel .................................................................................... 9-1/2”............................................. 9-1/2”

T-Slots, Number ............................................................................................... 3.................................................... 3

T-Slots, Size ................................................................................................. 5/8”................................................ 5/8”

T-Slots, Spacing ........................................................................................ 2-1/2”............................................. 2-1/2”

Table Weight Capacity .............................................................................. 500 lb............................................. 500 lb

Knee Travel ................................................................................................... 14”................................................. 14”

Dimensions:

Overall Dimensions, assembled ........................................... 55”W x 52”D x 77”H........................ 55”W x 52”D x 77”H

Shipping Dimensions ........................................................... 67”W x 56”D x 66”H........................ 67”W x 56”D x 66”H

Weights:

Net Weight (approx.) ............................................................................... 1617 lb........................................... 1610 lb

Shipping Weight (approx) ........................................................................ 1700 lb........................................... 1700 lb

The specifications in this manual were current at time of publication, but because of our policy of continuous
