6.0 Specifications

Model number .................................................................... JWL-1015 ............................................. JWL-1015VS

Stock number .......................................................................... 719100 ....................................................... 719110

Motor and electricals:

Motor type .....induction, totally enclosed fan cooled, capacitor start ................................................ brushed DC

Horsepower .......................................................... 1/2 HP (0.37kW) .................................. 1/2 HP (0.37kW) DC

Phase ......................................................................................single .......................................................... single

Voltage ............................................................................ 115 V only ..................................................... 90 V DC

Cycle ........................................................................................60Hz ........................................................... 60Hz

Listed FLA (full load amps) .........................................................5 A ........................................................... 3.2 A

Power transfer ........................................................................... belt ............................................................. belt

On/off switch ........................................ paddle style with safety key ....................... paddle style with safety key

Power cord (size/length) ....................... 3x18 AWG (0.823mm)/5 ft. ........................ 3x18 AWG (0.823mm)/5 ft.

Power plug installed ................................................................... yes ............................................................. yes

Recommended circuit size

.......................................................10A ............................................................. 10A

subject to local/national electrical codes.

Capacities:

Swing over bed .......................................................... 10” (254 mm) ............................................. 10” (254 mm)

Swing over tool rest base ....................................... 7.32” (186 mm) .......................................... 7.32” (186 mm)

Distance between centers ................................... 15.5” (393.7 mm) ....................................... 15.5” (393.7 mm)

Faceplate diameter ......................................................... 3” (76mm) .................................................. 3” (76mm)

Headstock:

Spindle taper ............................................................................. MT2 ............................................................ MT2

Spindle thread .................................................................... 1”x8 TPI ..................................................... 1”x8 TPI

Spindle bore ............................................................... 3/8” (9.5 mm) ............................................. 3/8” (9.5 mm)

Number of spindle speeds ............................................................. 6 ....................................... 3 ranges variable

Spindle speed ranges ................ 500, 840, 1240, 1800, 2630, 3975 ................. 600-3600; 300-1750; 200-1050

Number of indexing positions ...................................................... 24 ............................................................... 24

Tailstock:

Quill taper ................................................................................. MT2 ............................................................ MT2

Maximum quill travel ................................................... 2” (50.8 mm) .............................................. 2” (50.8 mm)

Hole through tailstock ................................................ 3/8” (9.5 mm) ............................................. 3/8” (9.5 mm)

Materials:

Bed .................................................................................... cast iron ..................................................... cast iron

Headstock .......................................................................... cast iron ..................................................... cast iron

Tailstock ............................................................................. cast iron ..................................................... cast iron

Tool support ....................................................................... cast iron ..................................................... cast iron

Tool support base .............................................................. cast iron ..................................................... cast iron

Dimensions:

Bed width ..................................................................... 5” (128 mm) ............................................... 5” (128 mm)

Tool support post diameter .......................................... 5/8” (16mm) ............................................... 5/8” (16mm)

Overall dimensions, assembled……………………….35”L x 18.1”W x 14.56”H (890 x 300 x 370 mm) ..............

Overall dimensions of shipping carton…………….30.51”L x 11.81”W x 17.1”H (775 x 300 x 435 mm) ..............

Weights:

Net ............................................................................... 77 lb (35 kg) ............................................ 72.6 lb (33 kg)

Shipping ................................................................. 82.5 lb (37.5 kg) ............................................ 78 lb (35.5 kg)

The specifications in this manual were current at time of publication, but because of our policy of continuous

improvement, JET reserves the right to change specifications at any time and without prior notice, without

incurring obligations.
