GlowPlug Power

Glow plug voltage, The glow plug will glow with the selected

voltage when the Change Value/Item key is pressed.

Default = 2.250V

Gas Flow

Sets the amount of starting gas that will flow when the turbine is

started. The range is from 10 to 100% adjustable in 10%

increments.
