Smoker valve
The ECU can directly control a smoker valve for injection of smoke fluid (e.g. diesel oil)
in the exhaust blast.
The smoker valve is of the same type as used for the fuel shut off.
The function of the smoker valve can be defined in the Limits menu
(Parameter: SmokerValve Ctrl)
The possible option for the parameter SmokerValve Ctr are:
Option Description
DISABLED
The smoker valve is not used, Æ valve is always closed !
Open if
AuxSw=0
Smoker-valve is opened if the AUX-Switch (3-Pos. switch)
is brought into the lower position (“OFF”-Position)
and the
turbine is running.
To be able to use this function it is necessary that the AUX-
channel func is ON, TrbCtrl is OFF and the smoker AUX-
ch SmokeCtrl is not set to DISABLED.
Open if
AuxSw=2
Smoker-valve is opened if the AUX-Switch (3-Pos. switch)
is brought into the upper position (“AUTO-OFF”-Position)
and the turbine is running.
To be able to use this function it is necessary that the AUX-
channel func is ON, TrbCtrl is OFF and the smoker AUX-
ch SmokeCtrl is not set to DISABLED.
