computer radio control system
EN
1. A.Loosen the screw
2. B. Slightly lift the lever
3. C B Turn the lock in the direction of the arrow and arrest the lever
in the upper position.
4. C Move the lever in the direction of the arrow to release the lever
B.
5. A. Tighten the screw
6. Loosen the screws E and D in a position so that tension is removed
from the stick.
B. Setting the multi-mode gimbal into the mode with locking
the middle position - elevator
B
2
1
3
A
C
E
D
5
20
