AUX1-3 ENABLE/DISABLE
AUX 1-3 is enable or disable. If enable then the auxiliary output
signal will be activated during the weld. If disable the auxiliary
output will stay open.
4. PULSED SCREENS
To get out of the pulsed sub menu all you have to do is press the left arrow.
PULSED WIRE
Pulsed Wire is on or off. If on, the wire will pulse, if off, it will feed
at the command speed.
LOW PERCENTAGE
Low % is the percentage of the wire feed speed when
commanded to move at the slower speed . Minimum value is 0.0,
Maximum value is 100.0.
WIRING PULSING
Wire Pulsing is either timed or synch. For timed, the high and low
time period is determined by High and Low Time. For synch the
high speed is when the weld current is in the high state and low
speed is during the low welding current.
HIGH TIME
If Wire Pulsing is in timed, this is the amount of time in seconds
that the wire will stay in the high wire feed. Minimum value is
0.05, Maximum value is 10.0.
