Jetline 9700W User Manual

Page 38
AUTO CALIBRATION SUB MENU
Pressing the right arrow will enter the user into the Auto Cal sub
menu. See appendix C for details on each auto calibration sub
menu and how to run auto calibration.
Appendix B 9700W Configuration Sub Menu Mode
You enter the Configuration mode from the program mode. To get out of the configuration sub
menu all you have to do is press the left arrow. When you leave the calibration sub menu all settings
will be saved to the main configuration permanent memory.
FORWARD JOG
Fwd Jog is the percentage of the high speed that is moved when
jogging forward. Minimum value is 5 and Maximum value is 100.
REVERSE JOG
Rev Jog is the percentage of the high speed that is moved when
jogging reverse. Minimum value is 5 and Maximum value is 100.
RAPID JOG
Rapid Jog is the percentage of the high speed that is moved when
doing a rapid jog or wire retract. Minimum value is 5 and
Maximum value is 100.
CALIB
4
llu
ON
HOUR METER
AUTO CAL
CLOSED LOOP
CONFIG
llu
25
25
RESTORE
FWD JOG
REV JOG
CONFIG
25
25
75
FWD JOG
REV JOG
RAPID JOG
CONFIG
25
75
YES
REV JOG
RAPID JOG
RAMP ENABLE
