running again at the same time and speed in item 3 or you can change to the other end of the
calibration.
TIME
This is the amount of time that the Auto calibration will run.
VALUE
This is the speed that the calibration will run.
MOVE
This menu line will allow the user to use the right and left buttons
to move the travel. Note: Other screen in Auto Cal the left arrow
will move the user out of the Auto Calibration sub menu.
ACTUAL
After running the test, this is the actual distance that was moved
during the test if it was programmed by time. If the test was
programmed using revolutions then it is the distance off from that
number of revolutions. If the move is short then you enter in
distance as a minus number, if over you enter the distance as a
positive number.
READ
After running a test this is the distance that the unit thought that it
moved. Note: This number cannot be changed.
