Jetson BOLT Guide

28
1.5 Securing the Bell
YOU WILL NEED THE PHILLIPS-HEAD SCREWDRIVER TIP.
1. LOOSEN BUT DO NOT REMOVE THE SCREW ON THE BELL CLAMP BY TURNING IT COUNTERCLOCKWISE FOR 1  2
ROTATIONS WITH THE SCREWDRIVER.
2. ROTATE THE BELL AROUND THE HANDLEBAR UNTIL THE BELL TAB IS IN A PLACE THAT CAN EASILY BE REACHED BY THE
RIDER’S LEFTHAND THUMB WHILE HOLDING ONTO THE HANDLEBAR.
3. TIGHTEN THE SCREW BY TURNING IT CLOCKWISE WITH THE SCREWDRIVER.
BELL
SCREW
BELL TAB
PHILLIPSHEAD
SCREWDRIVER TIP

Jetson BOLT Specifications

General

Motor Power	350W
Charging Time	4-5 hours
Foldable	Yes
Motor	350W
Max Rider Weight	120 kg
Brake	Disc Brake
Tires	8.5 inches
Max Load	120 kg
Brake Type	Disc Brake
Top Speed	25 km/h
Weight	14 kg
