Jetson BOLT Guide

31
2.2 Charging the Battery
IT CAN TAKE UP TO 5 HOURS TO BRING A DEPLETED
BATTERY TO FULL CHARGE.
1. CONNECT THE CHARGING CABLE WITH THE CHARGER.
2. PULL OPEN THE CHARGING PORT COVER ON YOUR BIKE.
3. PLUG THE CHARGING CABLE INTO THE WALL, AND THEN
PLUG THE CHARGER INTO THE CHARGING PORT.
4. WHEN THE INDICATOR LIGHT ON THE CHARGER CHANGES
FROM RED TO GREEN, YOUR BATTERY HAS REACHED FULL
CHARGE. REMOVE THE CHARGER FROM THE CHARGING
PORT AND UNPLUG THE CABLE FROM THE WALL OUTLET.
5. CLOSE THE CHARGING PORT COVER.
CHARGING PORT COVER
CHARGING PORT

Jetson BOLT Specifications

General

Motor Power	350W
Charging Time	4-5 hours
Foldable	Yes
Motor	350W
Max Rider Weight	120 kg
Brake	Disc Brake
Tires	8.5 inches
Max Load	120 kg
Brake Type	Disc Brake
Top Speed	25 km/h
Weight	14 kg
