FLAT WASHER
CLAMP BOTTOM
CLAMP TOP
CURVED WASHER
CLAMP LATCH
2. USING YOUR FINGERS, UNSCREW THE PREATTACHED BOLT ON
THE UNDERSIDE OF THE HANDLEBAR CLAMP.
3. REMOVE THE NUT AND FLAT WASHER. SET ASIDE.
4. PULL THE CLAMP LATCH UP AND OUT OF THE CLAMP,
ALONG WITH THE CURVED WASHER. SET ASIDE.
5. SEPARATE THE TOP PART OF THE CLAMP FROM ITS BASE BY
SLIDING IT OUT SIDEWAYS.
NUT
SLIDING IT
OUT SIDEWAYS
