18
5. HOLD THE STEM TUBE UPRIGHT AND CLOSE THE THE STEM CLAMP LATCH.
TROUBLESHOOTING: IF YOU CANNOT CLOSE THE LATCH WITH EASE, THE CLAMP IS TOO TIGHT. LOOSEN THE CLAMP BY
TURNING THE KNOB COUNTERCLOCKWISE FOR ½ ROTATION AT A TIME UNTIL YOU CAN CLOSE THE LATCH.
STEM CLAMP
STEM CLAMP KNOB
(*OPPOSITE SIDE;
NOT SHOWN)
HANDLEBAR
STEM TUBE
STEM CLAMP LATCH
