3. Preparing to Ride
1. PULL OPEN THE LATCH ON THE STEM CLAMP.
2. LOOSEN THE CLAMP KNOB BY TURNING IT COUNTERCLOCKWISE.
3. RAISE OR LOWER THE STEM UNTIL THE HANDLEBAR IS AT THE DESIRED HEIGHT.
IMPORTANT: NEVER RAISE THE HANDLEBAR SUCH THAT THE "MINIMUM INSERTION" MARK COMES INTO
VIEW ABOVE THE CLAMP.
4. WHILE HOLDING THE HANDLEBAR IN PLACE, RETIGHTEN THE CLAMP KNOB BY TURNING IT CLOCKWISE.
TROUBLESHOOTING: IF YOU CANNOT OPEN OR CLOSE THE CLAMP LATCH, THE KNOB MAY BE TOO TIGHT. LOOSEN THE
KNOB BY TURNING IT COUNTERCLOCKWISE FOR ½ ROTATION AT A TIME UNTIL YOU CAN UTILIZE THE LATCH.
5. CHECK THAT THE HANDLEBAR IS SECURE: USE YOUR HAND TO PUT DOWNWARD PRESSURE ON THE HANDLEBAR. IF THE
STEM SLIPS DOWN INTO THE STEM TUBE, BRING THE HANDLEBAR BACK TO POSITION AND TIGHTEN THE CLAMP BY FURTHER
TURNING THE KNOB CLOCKWISE.
3.1 Adjusting Handlebar Height
