2.6 Securing the Bell
YOU WILL NEED A PHILLIPS-HEAD SCREWDRIVER. (INCLUDED ON MULTI-TOOL WITH SOME MODELS)
1. LOOSEN (BUT DO NOT REMOVE) THE SCREW ON THE BELL CLAMP BY TURNING IT COUNTERCLOCKWISE FOR 1 - 2
ROTATIONS WITH A PHILLIPS-HEAD SCREWDRIVER.
2. ROTATE THE BELL AROUND THE HANDLEBAR UNTIL IT IS IN A PLACE THAT CAN EASILY BE REACHED BY THE RIDER'S
LEFT-HAND THUMB WHILE HOLDING ONTO THE HANDLEBAR.
3. WHILE HOLDING THE BELL IN THAT POSITION, TIGHTEN THE CLAMP BY TURNING THE SCREW CLOCKWISE WITH THE
SCREWDRIVER.
PHILLIPS-HEAD
SCREWDRIVER
BELL
BELL TAB
SCREW
HANDLEBAR
