2.7 Securing the Front Reector
YOU WILL NEED A PHILLIPS-HEAD SCREWDRIVER. (INCLUDED ON MULTI-TOOL WITH SOME MODELS)
1. ROTATE THE FRONT REFLECTOR CLAMP AROUND THE HANDLEBAR UNTIL THE REFLECTOR IS FACING THE FRONT OF THE BIKE.
2. SLIDE THE REFLECTOR TOWARDS THE CENTER OF THE HANDLEBAR UNTIL THE REFLECTOR CLAMP FEELS SNUG ON THE
THICKER PART OF THE HANDLEBAR.
3. IF NECESSARY, TIGHTEN THE CLAMP ON THE HANDLEBAR FURTHER BY TURN THE SCREW CLOCKWISE WITH A PHILLIPS-HEAD
SCREWDRIVER.
FRONT REFLECTOR
HANDLEBAR
PHILLIPS-HEAD SCREWDRIVER
SCREW
