3.4 Charging the Battery
CHARGER COMPATIBILITY:
· ONLY USE THE INCLUDED CHARGER OR ONE
OBTAINED DIRECTLY THROUGH JETSON LABELED
WITH PS65D420Y1500S OR THE PART SKU PJJ5-CH.
IT CAN TAKE UP TO 5 HOURS TO BRING A DEPLETED
BATTERY TO FULL CHARGE.
1. CONNECT THE CHARGING CABLE WITH THE CHARGER.
2. PULL OPEN THE CHARGING PORT COVER ON
YOUR E-BIKE.
3. PLUG THE CHARGING CABLE INTO THE WALL, AND THEN
PLUG THE CHARGER INTO THE CHARGING PORT.
4. WHEN THE INDICATOR LIGHT ON THE CHARGER TURNS
FROM RED TO GREEN, YOUR BATTERY HAS REACHED FULL
CHARGE. REMOVE THE CHARGER FROM THE CHARGING
PORT AND UNPLUG THE CABLE FROM THE WALL OUTLET.
5. CLOSE THE CHARGING PORT COVER.
FAILURE TO USE CORRECT CHARGER CAN
RESULT IN FIRE AND EXPLOSION, RESULTING IN
PROPERTY DAMAGE, INJURY, AND DEATH.
CHARGING PORT
WITH COVER
