35
2. ROTATE THE HANDLEBAR FORWARD OR BACKWARD TO REPOSITION IT.
3. WHILE HOLDING THE HANDLEBAR IN THE NEW POSITION WITH ONE HAND, USE THE OTHER HAND TO PUSH THE LATCH DOWN
AND BACK INTO THE CLOSED (LATCHED) POSITION.
TROUBLESHOOTING: IF THE HANDLEBAR DOES NOT STAY SECURE WITH THE CLAMP CLOSED AROUND IT, YOU NEED TO
TIGHTEN THE CLAMP. FIRST, PULL THE CLAMP LATCH OPEN. THEN, TIGHTEN THE KNOB BY TURNING IT CLOCKWISE FOR A FEW
ROTATIONS, THEN CLOSE THE CLAMP LATCH.
3
2
HANDLEBAR CLAMP LATCH
HANDLEBAR CLAMP KNOB
HANDLEBAR
