4. PLACE THE WHEEL IN THE FRONT FORK SUCH THAT THE FOLLOWING CONDITIONS ARE MET:
· THE SPACES MENTIONED IN STEP 3 REST IN THE WEDGES ON THE END OF THE FRONT FORK.
· THE WASHERS AND AXLE NUTS ARE ON THE OUTER SIDES OF THE FORK.
· THE BRAKE MECHANISM ON THE WHEEL IS ON THE LEFT SIDE OF THE BIKE.
AXLE NUT & WASHER
FRONT FORK
FRONT FORK
FRONT FORK WEDGE SPACE
BRAKE
