Belts (6)
IMPORTANT: Use a pair of belts A55.
a) Install the belts (6) as ilustrated aside.
NOTE: If necessary displace the motor lenghwise (see
arrows aside) to assemble the belts, see instructions in
this manual.
b) Adjust the belt tightening according instructions in this
manual.
c) Install the shield (5a) and fasten it with four nuts (5b).
6
5b
5a
