JF C-40 S2 - Page 51

51
N°
Code
Specification
Quantity
1
02.056248
Machine supporting chain
1
2
05.000264
Lifting tube (chute) hinge pin
1
3
05.001813
Universal ring locking pin 7/1
1
4
05.045012
3rd point hitching pin
1
5
05.001236
Cutter pin 3/16" x 1.1/2"
2
6
02.045091
Pin drawer
1
7
02.045001
Safety pins
5
8
05.001475
Spring pin 05 x 55 mm
2
9
05.001465
Spring pin 08 x 55 mm
2
10
05.000451
Hex bolt 7/16" x 1.1/2" Gr 5
4
11
05.000842
Hex nut 7/16"
6
12
05.000340
Hex bolt 3/8" x 2"
2
13
05.000431
Hex bolt 7/16" x 1.1/4"
2
14
05.000990
Lock washer 7/16"
6
15
05.056587
Hex bolt 7/16" x 1" Gr 5
2
16
05.000290
Hex bolt 3/8" x 3/4"
8
17
05.000980
Lock washer 3/8"
8
18
02.051162
Washer 3/8"
8
19
05.000832
Hex nut 3/8"
10
22
02.048642
Cutting gear C-3
1
23
02.048652
Cutting gear C-5
1
24
02.048662
Cutting gear C-8 (come assembled on the machine from the factory)
1
25
02.048672
Cutting gear C-11 (come assembled on the machine from the factory)
1
26
02.048682
Cutting gear C-14
1
27
02.048692
Cutting gear C-18
1
28
02.048735
Sharpener’s handle
1
29
05.002492
Instructions manual of this equipment
1
OPERATION TECHNICAL MANUAL - HARVESTER JF C40 C60 and C120 SERIES 2
English
