JGaurora JGMAKER Magic User Manual

With User to Create Better Product
11
Suite
Step
Assembly process
Detail
Accessories
Z
axis
1st
2nd
6.Z-axis Motor Suite
9. Z-axis Limit
switch Base
11. 2040 aluminum
profile
0
0
0
0
0
0
0
0
0
0
0
0
11. 2040 aluminum
profile
1. Printer Base
Note ： The profile side with the
counterbore is placed on the
outside of the machine.
The other side is attached to the
Cheese head
M5*40
Note：1. The profile side
with the counterbore is
placed on the outside of
the machine.
To easy install the Z-axis
limit swithc base, the
coupling can be remove
first
Couple
