With User to Create Better Product
13
print
er
3rd
4th
10. T type screw rod
Note：After the T-type screw
rod is installed in the
coupling, please tighten the
screws to ensure that the
machine is properly driven.
16. Top decoration
Button-headed
M5*8
Screw position
