Making connections simpler
06
Specications and Features
Category Item Parameter Remarks
Hardware
Memory 1GB+16GB /
Standard
version
4G
FDD: B1/B3/B5/B7/B8/B19/B20
TDD: B38/B39/B40/B41
3G WCDMA: B1/B2/B5/B8
2G GSM: 850/900/1800/1900
American
Version
4G
FDD: B2/B4/B5/B7/B12/B17
TDD: B38/B41
3G WCDMA: B2/B4/B5
2G
GSM: 850/1900
WiFi 2.4GHz 802.11/b/g/n
GNSS Support GPS/BDS
Microphone Support For remote voice communication
Speaker Support To notify drivers of status or events
Interface/
Key
Reset key Support On the main unit
Interface Micro USB For commissioning and upgrade
Others
Power supply Fuse box B+/ACC/GND
Supply voltage DC 9-30V /
Operating
temperature
-20℃ ~ 65℃ /
