01
Overview


Pin Number Pin Name description
4 GND(-) Ground
5 GND(-) Ground
6 CAN_H CAN high
7 K-Line
14 CAN_L CAN low
15 L-Line
16 VCC(9-36)V DC(+) Power supply(9-36V DC)
