06
4.2 Basic characteristics
GNSS
Positioning system GPS/BDS
Frequency L1
Positioning accuracy <5 meters
Track sensitivity -162 dBm
Acquisition sensitivity -148 dBm (cold) /-156 dBm (hot)
TTFF (open sky)
Avg. hot start ≤ 1sec
Avg. cold start ≤ 32sec
Power
Battery 50mA/3.7V
Input voltage 9-36VDC
Cellular
Communication network LTE Cat1 + GSM
Frequency
Cat1 LTE-FDD B1/B3/B7/B8/B20/B28
LTE-TDD B34/B38/B39/B40/B41
GSM: B2/B3/B5/B8
Physical specication
Dimensions 51.0 x 50.0 x 22.0mm（LxWxH）
Weight 55g
