The name of each part:
1. Indicator Light
2. Control Panel
3. Power Switch
4. Channel Increase Button
5. Channel Reduce Button
6. Battery Hatch
7. Hot Shoe fixed nut
8. 1/4"-20 Threaded Sockets
9. ACC socket
10. Hot Shoe mount
Receiver(WT-868RX)
