| Fathom f112 & f113Page 36
Specifications
f112
fathom home subwoofer
f113
fathom home subwoofer
Enclosure Type: Sealed Sealed
Driver: Single 12-inch (nominal diameter) Single 13.5-inch (nominal diameter)
Frequency Response (anechoic):
21-119 Hz (+1.5dB)
–3 dB at 19 Hz / 150 Hz
–10 dB at 17 Hz / 167 Hz
20-86 Hz (+1.5dB)
–3 dB at 18 Hz / 127 Hz
–10 dB at 16 Hz / 154 Hz
Effective Piston Area: 84 sq. in. (0.0542 sq. m) 107.35 sq. in. (0.0693 sq. m)
Effective Displacement: 287 cu. in. (4.7 liters) 386 cu. in. (6.3 liters)
Amplifier Power: 1500 watts RMS short-term 2500 watts RMS short-term
Dimensions: (H) Height x (W) Width x (D) Depth
Height Dimensions include feet.
18.5 in. x 15 in. x 17.625 in.
470 mm x 381 mm x 448 mm
19.625 in. x 16.5 in. x 19.25 in.
498 mm x 419 mm x 489 mm
Net Weight: 115 lbs. (52 kg) 130 lbs. (59 kg)
Cabinet Finishes: High-Gloss Black or Satin Black High-Gloss Black or Satin Black
FEATURES
Unbalanced Inputs:
Stereo or Mono (two RCA jacks)
Balanced Inputs:
Stereo or Mono (two female XLR jacks)
Output To Slave:
Balanced (one male XLR jack)
Input Modes:
Master or Slave
Level Modes:
Reference (xed gain) or Variable from
full mute to +15dB over reference gain
Power Modes:
O, On or Automatic Signal-Sensing
Light Modes:
O, On or Dim
Low Pass Filter Mode:
O, 12 dB per octave or 24 dB per octave
Low Pass Filter Cuto Frequency:
Variable from 30 Hz – 130 Hz
Polarity:
0 or 180 degrees
Phase:
Variable from 0 – 280 degrees
E.L.F. Trim:
Variable from –12 dB to +3 dB at 25 Hz
Automatic Room Optimization (A.R.O.)
with included laboratory-grade
calibration microphone, defeatable.
“JL Audio”, “Fathom” and the JL Audio logo are registered trademarks of JL Audio, Inc.,“Ahead of the Curve” is a trademark of
JL Audio, Inc. Due to continuous product development, all specifications are subject to change without notice.
JLA-SKU011172-08-2008rev7 • Printed in USA • ©2008 JL Audio, Inc. • U.S. PATENTS: #5,734,734 #5,949,898 #6,118,884
#6,229,902 #6,243,479 #6,294,959 #6,501,844 #6,496,590 #6,441,685 #5,687,247 #6,219,431 #6,625,292 #D472,891
#D480,709 Other U.S. & Foreign patents pending. For more detailed information please visit us online at www.jlaudio.com.
(954) 443-1100
www.jlaudio.com
10369 NORTH COMMERCE PARKWAY • MIRAMAR, FLORIDA • 33025 • USA
