SECTION 7 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE
7-2 – JLG Lift – 3121189
7.2 GENERAL SPECIFICATIONS
Machine Specifications
Platform Data
SPECIFICATION 19AMI
Gross Machine Weight:
(Platform Empty):
1,140 lb.
(517kg)
Machine Height:
(Platform Stowed)
78 in.
(1.9m)
Machine Base - Overall :
(Length x Width)
33 x 47.5 in.
(83cm x 120cm)
Maximum Wind Speed:
(Machine rated for indoor use only)
0 mph
(0kph)
Maximum Horizontal Manual Side Force:
(Platform fully extended with Maximum load)
50 Pound Force
(222 Newtons)
Maximum Hydraulic System Pressure: Pressure Relief Set to
2800 PSI (193 bar)
at Factory
SPECIFICATION 19AMI
Occupants:
(Persons allowed in Platform)
1
Platform Capacity:
(All platforms except Extendible) ANSI/CSA: 350 lb. (160 kg)
Ex ten dib le P lat for m: ANS I ON LY: 300 lb. (135 kg)
Platform Height - Mast Fully Extended :
(Ground to Platform Floor):
19 ft.
(5.8 m)
Platform Working Height:
(Average Size Person)
26 ft.
(7.92 m)
Pl atf orm Cy cle Pe r for ma nce : Lif t Up: 31-34
(in seconds) (w/max. rated load) Lif t Down: 18-25
