SECTION 3 - USER RESPONSIBILITIES AND MACHINE CONTROLS
3-12 – JLG Lift – 3120742
9. Platform Rotate.
(35/n35/40/n40/45 electric)
The PLATFORM ROTATE control switch allows the
operator to rotate the basket to the left or right when
positioned to the desired direction.
10. Function Speed Control.
Adjusts speed of Boom and Swing Functions.
Rotate CCW for slower speed and CW for faster
speed. Adjust Drive Function to creep. Rotate
CCW until the Function Control knob clicks.
11. Machine Out Of Level.
This red illuminator indicates that the chassis is on a
slope (over 5 degrees). If the boom is above horizon-
tal and the machine is on a 5 degree slope, an alarm
will sound and CREEP is automatically activated.
12. Horn.
A push-type HORN switch supplies electrical power
to an audible warning device when pressed.
13. Circuit Breakers.
The circuit breakers open (pop out) to indicate a
short or overload somewhere on the machine.
14. 110 Volt AC Outlet.
This feature allows electrical power to be supplied
to the platform. Plug an extension cord into a
grounded 110 VAC outlet and then into the plug on
the right side of the hood. Power will now be sup-
plied to the outlet in the basket to run portable elec-
tric tools, lights, etc.
TO AVOID SERIOUS INJURY, DO NOT OPERATE MACHINE IF ANY
CONTROL LEVERS OR TOGGLE SWITCHES CONTROLLING
PLATFORM MOVEMENT DO NOT RETURN TO THE OFF POSITION
WHEN RELEASED.
