JLG 460SJ - Bolt-On External Fall Arrest System

SECTION 4 - BOOM & PLATFORM
3121671 4-57
8
7
1,2,3,4
6
9
5
Figure 4-21. Bolt-On External Fall Arrest System
1. Belleville Washer
2. Washer
3. Hex Nut
4. Jam Nut
5. LH Bracket
6. Attachment Ring
7. Cable
8. RH Bracket
9. Decal
