JLG 460SJ - Main Valve Harness - Sheet 7 of 7

SECTION 7 - BASIC ELECTRICAL INFORMATION & SCHEMATICS
7-66 3121671
HV378 SWING RIGHT
CONN
POS
WIRE
COLOR
WIRE LABEL GAUGE JACKET To
1 WHT 4-26 SWING RIGHT 18 AWG GXL CO69-J2 (35)
2 BLK 000-40-37 CF 18 AWG GXL S389 (1)
HV383 PLTF ROT L
CONN
POS
WIRE
COLOR
WIRE LABEL GAUGE JACKET To
1 WHT 4-9 ROTATE LEFT 18 AWG GXL CO69-J2 (10)
2 BLK 000-40-19 18 AWG GXL S384 (1)
HV366 MAIN DUMP
CONN
POS
WIRE
COLOR
WIRE LABEL GAUGE JACKET To
1 WHT 4-14 MAIN DUMP 18 AWG GXL CO69-J2 (13)
2 BLK 000-40-25 GND 18 AWG GXL CO69-J2 (30)
HV381 PLTF LVL UP
CONN
POS
WIRE
COLOR
WIRE LABEL GAUGE JACKET To
1 WHT 4-8 LEVEL UP 18 AWG GXL CO69-J2 (5)
2 BLK 000-40-22 18 AWG GXL S386 (1)
HV373 STEER RIGHT
CONN
POS
WIRE
COLOR
WIRE LABEL GAUGE JACKET To
1 WHT 4-21 STEER RIGHT 18 AWG GXL CO69-J2 (8)
2 BLK 000-40-32 GND 18 AWG GXL S415 (1)
HV371 MAIN TELE IN
CONN
POS
WIRE
COLOR
WIRE LABEL GAUGE JACKET To
1 WHT 4-19 MAIN TELE IN 18 AWG GXL CO69-J2 (4)
2 BLK 000-40-31 18 AWG GXL S386 (1)
Figure 7-67. Main Valve Harness - Sheet 7 of 7
