SECTION 6 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE
3121220 – JLG Lift – 6-7
Batteries (Electric Machines)
JLG MACHINES EQUIPPED WITH DELTA Q BATTERY CHARGERS ARE
DESIGNED FOR THE BEST PERFORMANCE WITH OEM FACTORY
APPROVED BATTERIES.
APPROVED JLG REPLACEMENT BATTERIES ARE AVAILABLE
THROUGH JLG' S AFTERMARKET PARTS DISTRIBUTION CENTERS OR
JLG' S AFTERMARKET PROGRAMS. FOR ASSISTANCE WITH PROPER
BATTERY REPLACEMENT, PLEASE CONTACT YOUR LOCAL JLG SUP-
PORT OFFICE.
BATTERIES APPROVED BY JLG HAVE BEEN TESTED FOR COMPATIBIL-
ITY WITH THE ALGORITHM PROGRAMMING OF THE DELTA Q BATTERY
CHARGER TO OPTIMIZE BATTERY LIFE AND MACHINE CYCLE TIMES.
THE USE OF NON APPROVED BATTERIES IN YOUR JLG EQUIPMENT
MAY RESULT IN PERFORMANCE ISSUES OR BATTERY CHARGER
FAULT CODES. JLG ASSUMES NO RESPONSIBILITY FOR SERVICE OR
PERFORMANCE ISSUES ARISING FROM THE USE OF NON APPROVED
BATTERIES.
Critical Stability Weights
Table 6-5. Battery Specifications
Type 706HD EVL16A-A (AGM)
Voltage 6 6
Reserve Capacity 810 minutes 841 min.
Amp Hour Rating @ 20 hour rate - 375 @ 20 hour rate - 390
Table 6-6. Critical Stability Weights
COMPONENT lbs kg
Platform 780 354
Platform Extension 360 163
Foam Filled Tires 207 94
Batteries (Electric
Machines - Each)
111 50.3
